Join the fascinating world of microcontrollers with our myAVR boards!

• For everybody, who likes to tinker we recommend our assembly kits
• If you decide to equip the board by yourself you are going to learn a lot even before starting to program the microcontroller
• Incl. an assembly instruction which is also in our download
• Analogue photo sensor to experiment with different brightnesses
• 4 board feets which protect the board against scratches and other damages
• with ATmega8
• 8 kByte flash
• 512 Bytes EEPROM
• 1 kByte internal SRAM
• 2x 8 Bit Timer/Counter
• 1x 16 Bit Timer/Counter
• 6x analoge-digital-comparator channels
• Real Time Counter
• 23 digital inputs and outputs


• Driver are available for
  • Windows CE, Windows 2000 / 2003 / XP / Vista / Windows 7
  • Linux
  • MacIntosh OSX
  => USB driver for myAVR products

  => you can download more driver at www.silabs.de .

Scope of supply:

• 1 Microcontroller ATmega8
• 1 Mini USB connection
• 1 green LED
• 1 yellow LED
• 1 red LED
• 3 Capacitor 100 nF
• 2 Capacitor 22 pF
• 3 Resistor 1,2 kOhm
• 2 Resistor 10 kOhm
• 1 Photo sensor
• 1 Inductance 10 µH
• 1 Standard quartz 3,68 MHz
• 2 Potentiometer
• 2 Shaft for potentiometer
• 3 Miniature button
• 1 Speaker
• 1 Female connector
• 1 Board

Recommended articles (not included)

• ISP connection
• IC socket
• Skirting board
• Multi-Pin connector
• Foot for the board
• Pin connector 6pole

Supported controller:

• ATmega8/48/88/168/328
• ATtiny48/88
